Description
Product Availability Notice:
This item has been discontinued, see replacement and updated kit part number: 54-41262 for details.
Parts List:
| Label | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 21-90049 (Gray Media) | Pro DRY S Air Filter | 1 |
| 1 | 24-91039 (Blue Media) | Pro 5R Air Filter | 1 |
| 2 | 05-00854 | Housing | 1 |
| 3 | 05-00854 | Cover | 1 |
| 4 | 05-00947 | Tube Assembly | 1 |
| 4 | 03-50102 | Button head screws | 4 |
| 5 | 03-50114 | Screw, hex head M6 x 1 x 25 | 2 |
| 6 | 03-50070 | Washers, M6 flat | 2 |
| 7 | 03-50059 | Nut, M6 hex | 2 |
| 8 | 05-00118 | MAF sensor gasket | 1 |
| 9 | 03-50045 | Screws, #8-32 x 5/8 | 2 |
| 10 | 03-50058 | Washers, M6 wavy | 2 |
| 11 | 03-50066 | T-20 torx bit | 1 |
| 12 | 05-00864 | Tube | 1 |
| 13 | 03-50010 | Clamps, #072 | 2 |
| 14 | 03-50008 | Clamps, #052 | 2 |
| 15 | 05-01106 | Coupler straight 3 x 2 | 1 |
| 16 | 05-01201 | Coupler, hump 4-1/8 x 3 | 1 |
| 17 | 03-50139 | Grommet | 1 |
| 18 | 03-50023 | Clamp, mini #012 | 1 |
| 19 | 03-50178 | Elbow, plastic | 1 |
Emissions Disclaimer:
Some or all of the applications listed are 50-state exempt.
