Description
The Mishimoto MMCPKG-MUS-67 Cooling Package bundles a 3-row brazed aluminum radiator, an aluminum fan shroud with a high-flow 16-inch electric fan, and a digitally calibrated thermostat into a single, easy-to-order upgrade for classic Ford Mustang and Mercury Cougar owners. Built with an all-aluminum core and cast aluminum end tanks, this Mishimoto cooling system is engineered to keep pace with everything from weekend cruising to drag strip runs.
Instead of piecing together a radiator, shroud, and thermostat separately, this Mishimoto cooling package delivers a matched system designed to work together. The radiator’s tube-and-fin aluminum core and internal transmission oil cooler help manage both coolant and transmission fluid temperatures, while the included 16-inch Mishimoto slim electric fan replaces the failure-prone factory mechanical fan and moves over 1850 CFM of air through the core. The Mishimoto thermostat opens at 180°F, well below the 195°F activation point of a standard thermostat, so coolant starts circulating through the engine sooner and helps keep temperatures in check. Every component in this cooling package is backed by the Mishimoto Lifetime Warranty.
Vehicle Applications
This Mishimoto cooling package is built for the 1967-1968 Ford Mustang and the 1967-1968 Mercury Cougar. Owners of these classic Ford and Mercury platforms can drop in this matched radiator, fan shroud, and thermostat combination as a direct cooling system upgrade over the aging factory setup.
Features
- 3-row brazed aluminum radiator core
- All-aluminum fan shroud and radiator construction for increased heat and pressure tolerance
- Billet aluminum radiator fill neck
- Internal transmission oil cooler built into the radiator
- High-flow 16-inch electric fan delivering over 1850 CFM of airflow, shipped pre-installed to the shroud
- Aluminum fan shroud replaces the failure-prone stock mechanical fan
- Mishimoto thermostat opens at 180°F versus the stock 195°F activation point, allowing coolant to flow sooner and helping reduce engine temperatures
- Digitally calibrated thermostat for precise, consistent operation
- Package includes Mishimoto radiator, Mishimoto radiator cap, magnetic drain plug, aluminum fan shroud, 16-inch Mishimoto slim electric fan, mounting hardware, and Mishimoto thermostat
- Backed by the Mishimoto Lifetime Warranty
- Note: a standard length water pump may cause fitment issues with this radiator and fan shroud combination; Mishimoto recommends installing a short neck water pump and pulley to avoid clearance issues
Specifications
- Brand: Mishimoto
- Part Number: MMCPKG-MUS-67
- Core Material: Aluminum
- Tank Material / End Tank Material: Aluminum
- Core Construction: Tube-and-Fin
- End Tank Construction: Cast
- Grade Type: Performance
- Flow Type: Down Flow
- Overall Height: 22.5 in
- Overall Length: 21 in
- Overall Width: 5.4 in
- Core Height: 19.6 in
- Core Length: 16.2 in
- Core Thickness: 2.5 in
- Inlet Diameter: 1.5 in (Top Right)
- Outlet Diameter: 1.75 in (Bottom Right)
- Drain Plug Thread Size: M12 – 1.5 (Metric)
- Internal Transmission Oil Cooler: Yes
- Radiator Cap Included: Yes
- Drain Plug Included: Yes
- Thermostat Included: Yes
- Mounting Hardware Included: Yes
- Electric Fan: 16-inch, over 1850 CFM airflow; fan assembly Length 22.50 in, Height 17.5 in, Width 0.79 in
- Thermostat Activation Temperature: Mishimoto 180°F/82°C versus stock 195°F/90.5°C
Frequently Asked Questions
What is included in the Mishimoto MMCPKG-MUS-67 cooling package?
The package includes a Mishimoto radiator, Mishimoto radiator cap, magnetic drain plug, aluminum fan shroud, 16-inch Mishimoto slim electric fan, mounting hardware, a Mishimoto thermostat, and the Mishimoto Lifetime Warranty.
Which vehicles does this Mishimoto cooling package fit?
This cooling package fits the 1967-1968 Ford Mustang and the 1967-1968 Mercury Cougar.
How much airflow does the included electric fan provide?
The included 16-inch Mishimoto slim electric fan provides over 1850 CFM of airflow and is shipped pre-installed to the shroud.
At what temperature does the Mishimoto thermostat open compared to a stock thermostat?
The Mishimoto thermostat opens at 180°F (82°C), compared to a standard thermostat’s 195°F (90.5°C) activation temperature, allowing coolant to flow through the engine sooner.
Does the radiator include a transmission fluid cooler?
Yes, the radiator has an internal transmission oil cooler built in to help manage transmission fluid temperatures.
Is there anything special to know about water pump compatibility?
Yes, a standard length water pump may cause fitment issues with this radiator and fan shroud combination, so Mishimoto recommends installing a short neck water pump and pulley to avoid clearance issues.
