Description
The Mishimoto MMINT-RS-16SL is a direct-fit, Sleek Silver bar-and-plate intercooler engineered specifically for the 2016-2018 Ford Focus RS and its 2.3L EcoBoost engine. Whether you spend your weekends on track, enjoy spirited backroad drives, or simply want your RS to stand out, this forced induction upgrade is built to handle the abuse without compromise. It’s a true bolt-on performance part that requires no modification for installation.
This forced induction intercooler boosts the induction system’s cooling capacity with a 36-percent increase in internal core volume and a 214-percent increase in external fin surface area compared to the factory unit, translating into real gains in air-cooling efficiency. The all-aluminum, TIG-welded core reduces air outlet temperature by almost 40-percent while minimizing the inlet/outlet pressure drop across the core, improving heat transfer at both idle and cruising speeds. Owners running this Mishimoto performance induction upgrade with a stock tune have seen bolt-on gains of 7 whp and 8 ft-lbs of torque. Included left and right diversion plates direct airflow through the intercooler core for maximum efficiency, and the stock mounting location keeps the radiator and AC condenser airflow path clear.
Vehicle Applications
This intercooler is a specific-fit part designed exclusively for the 2016-2018 Ford Focus RS equipped with the 2.3L EcoBoost engine. It functions with all factory equipment on these model years, and it is also compatible with Mishimoto’s own upgraded intercooler pipes as well as most aftermarket intercooler pipe kits, giving Focus RS owners flexibility as they build out their forced induction system.
Features
- Direct fit for the 2016-2018 Ford Focus RS – no modification necessary for installation
- 36-percent increase in internal core volume and 214-percent increase in external fin surface area over stock
- Reduces air outlet temperature by almost 40-percent while minimizing inlet/outlet pressure drop
- Includes left and right air diversion plates to direct air through the core for maximum efficiency
- Stock mounting location prevents airflow blockage to the radiator and AC condenser
- All-aluminum, TIG-welded bar-and-plate core construction
- Fits with stock, Mishimoto, and most aftermarket intercooler pipe kits
- Delivers a 7 whp and 8 tq bolt-on power increase with a stock tune
- Available in Sleek Silver (this listing) or Stealth Black finishes
- Backed by the Mishimoto Lifetime Warranty
- Includes (1) Mishimoto Intercooler, (1) Left & Right Diversion Plate, and mounting hardware
Specifications
- Brand: Mishimoto
- Part Number: MMINT-RS-16SL
- Product Type: Forced Induction
- Core Type: Bar-and-Plate
- Core Material: Aluminum
- Inlet Tank Material: Aluminum
- Core Color: Silver
- Grade Type: Performance
- Universal or Specific Fit: Specific
- Overall Length: 36.75 in
- Overall Width: 8.2 in
- Overall Height: 8.3 in
- Core Length: 25.6 in
- Core Height: 8.3 in
- Inlet Outside Diameter: 2.75 in
- Outlet Outside Diameter: 2.75 in
- Inlet Fitting Gender: Male
- Outlet Fitting Gender: Male
- Weight: 33 lbs
- Applications: 2016-2018 Ford Focus RS
- Engine Codes: 2.3L EcoBoost
- Includes: (1) Mishimoto Intercooler, (1) Left & Right Diversion Plate, Mounting Hardware, Mishimoto Lifetime Warranty
- Installation Note: 27 in-lbs (3NM) recommended for all T-bolt and constant-tension T-bolt clamps; these clamps have an operating range of 18-35 in-lbs (2-4NM); do not exceed the maximum torque rating of 35 in-lbs (4NM)
Frequently Asked Questions
What vehicles is the Mishimoto MMINT-RS-16SL intercooler designed for?
This intercooler is a specific fit for the 2016-2018 Ford Focus RS with the 2.3L EcoBoost engine.
Does this intercooler require any modifications to install?
No, it is designed to function with all factory equipment on the 2016-2018 Focus RS, making it a true bolt-on part with no modification necessary.
What performance gains can I expect from this intercooler?
With a stock tune, this intercooler provides a bolt-on power increase of 7 whp and 8 tq, along with a reduction in air outlet temperature of almost 40-percent.
What is the core construction of this intercooler?
It uses an all-aluminum, TIG-welded bar-and-plate core with a 36-percent increase in internal core volume and a 214-percent increase in external fin surface area compared to stock.
What is included with the Mishimoto MMINT-RS-16SL intercooler?
The kit includes (1) Mishimoto Intercooler, (1) Left & Right Diversion Plate, mounting hardware, and the Mishimoto Lifetime Warranty.
Is this intercooler compatible with aftermarket intercooler pipes?
Yes, it fits with stock, Mishimoto, and most aftermarket intercooler pipe kits.
