Description
The Mishimoto MMINT-MUS4-15SL is a purpose-built intercooler engineered exclusively for the 2015-2023 Ford Mustang EcoBoost, the first turbocharged 4-cylinder Mustang in over 30 years to produce over 300 horsepower. Where the factory tube-and-fin cooler heat soaks after just a few hard pulls, this Mishimoto bar-and-plate core is built to hold intake air temperatures down lap after lap, run after run. It’s a direct-fit unit that requires no modification to install.
As a forced induction component, this intercooler is central to keeping a turbocharged induction system performing consistently under repeated boost. Turbocharged engines generate extremely hot charge air quickly, and any forced induction setup is only as strong as its ability to shed that heat before it re-enters the engine. Mishimoto’s performance induction cooler addresses that head-on with a 58-percent increase in core size, a 25-percent increase in internal core volume, and a 165-percent increase in external fin surface area compared to stock, reducing intake air temperatures by 35°F (19.45°C) with minimal pressure loss. Cast, CFD-tested end tanks and an in-tank air diverter on the hot side keep airflow moving efficiently through the core, so the force induction system delivers cooler, denser air run after run rather than fading as the session goes on.
Vehicle Applications
This intercooler is a specific-fit part engineered for the 2015-2023 Ford Mustang EcoBoost and 2015-2023 Ford Mustang EcoBoost Premium, both built on the S550 chassis with the 2.3L EcoBoost engine. Mishimoto’s engineers designed it to mount in the stock location, working with the factory active grille shutters and avoiding airflow blockage to the radiator and AC condenser, so fitment on these model years is a bolt-on affair with no bumper cover removal required.
Features
- Direct-fit for the 2015-2023 Ford Mustang EcoBoost, no modification required
- Bar-and-plate core construction in aluminum for a highly efficient forced induction cooler
- 35°F (19.45°C) reduction in intake air temperature with minimal pressure loss
- 58-percent increase in core size; 25-percent increase in internal core volume and 165-percent increase in external fin surface area versus stock
- Cast end tanks, CFD tested for maximum airflow, with an in-tank air diverter on the hot side
- Mounts in the stock location, retaining the factory active grille shutters and preventing airflow blockage to the radiator and AC condenser
- Installs in under 2 hours without removing the front bumper cover
- Precision TIG-welded, all-aluminum construction
- Available in Sleek Silver or Stealth Black finish
- Compatible for use with the Mishimoto Mustang EcoBoost Oil Cooler Kit
- Backed by the Mishimoto Lifetime Warranty
Specifications
- Part number: MMINT-MUS4-15SL
- Core type: Bar-and-Plate
- Core material: Aluminum; Inlet tank material: Aluminum
- Core color: Silver
- Overall length: 30.3 in; Overall height: 6.8 in
- Core height: 5.75 in; Core length: 21.06 in
- Inlet outside diameter: 2.56 in (Male); Outlet outside diameter: 2.56 in (Male)
- Universal or specific fit: Specific
- Grade type: Performance
- Maximum recommended horsepower: 550
- Engine code: 2.3L EcoBoost; Chassis code: S550
- CARB EO Number: D-759-23
- Includes: (1) Mishimoto Intercooler, (1) M6 x 1.0 x 20 flange bolt, (1) M4 x 0.7 x 12 button head bolt, (1) M4 lock washer, and the Mishimoto Lifetime Warranty
Frequently Asked Questions
Which vehicles does this intercooler fit?
The Mishimoto MMINT-MUS4-15SL is a specific fit for the 2015-2023 Ford Mustang EcoBoost and 2015-2023 Ford Mustang EcoBoost Premium (S550 chassis, 2.3L EcoBoost engine).
How much does it lower intake air temperatures?
It reduces intake air temperatures by 35°F (19.45°C) with minimal pressure loss.
Does it require any modification to install?
No, it is a direct-fit unit that installs in the stock location in under 2 hours without removing the front bumper cover.
Will it interfere with the factory active grille shutters or cooling components?
No, it’s engineered to work with the stock active grille shutters and mounts in the stock location to prevent airflow blockage to the radiator and AC condenser.
What colors are available?
The intercooler is available in Sleek Silver or Stealth Black finish.
What warranty is included?
It is backed by the Mishimoto Lifetime Warranty.
