Description
The Mishimoto Performance Fan Shroud Kit (MMFS-MUS-67) is a purpose-built electric fan and aluminum shroud assembly engineered exclusively for classic Ford Mustang and Mercury Cougar cooling systems. It permanently retires the failure-prone stock mechanical fan, replacing it with a slim 16-inch high-flow electric fan capable of moving over 1850 CFM of air. Every kit mounts exclusively to the Mishimoto Performance Aluminum Radiator, giving these classics a modern, reliable cooling upgrade without cutting or bending anything.
Under the Cooling category, this Mishimoto fan shroud kit delivers real, measurable benefits: it drops mechanical drag from a belt-driven fan, improves airflow across the radiator core, and gives owners the option to add total control over coolant temperatures with the optional Mishimoto Adjustable Fan Controller Kit. The all-aluminum shroud and plug-in electric fan are designed as a matched system, so builders get a clean, factory-fit look with performance-grade function. Backed by the Mishimoto Lifetime Warranty, this shroud kit is built for drivers who want dependable cooling on a car that’s decades old but still driven hard.
Vehicle Applications
This fan shroud kit is designed for 1967-1970 Ford Mustang Base models, plus the 1970 Ford Mustang Grande and 1970 Ford Mustang Mach 1. Shelby GT-350 coverage spans 1967 and 1969-1970, and Mercury Cougar Base models are covered for 1967-1969. Applicable engines across this lineup include the 289ci (4.7L) V8, 302ci (4.9L) V8, and 351ci (5.8L) V8.
Features
- Includes a high-flow 16-inch electric fan producing over 1850 CFM of airflow
- All-aluminum shroud and housing construction with a brushed, silver finish
- Optional fan controller provides complete control of coolant temperatures at idle
- Designed to mate exclusively with the Mishimoto Performance Aluminum Radiator
- Replaces the failure-prone stock mechanical fan
- No cutting or bending of the shroud required for installation
- Includes all mounting hardware for a straightforward install
- Electric fan is plug-in and shipped pre-installed to the shroud (may require additional wiring)
- Backed by the Mishimoto Lifetime Warranty
Specifications
- Shroud material: Aluminum, silver color, brushed finish
- Fan diameter: 16 inches
- Blade quantity: 10, plastic material, black color, straight blade type
- Maximum airflow: 1850 CFM
- Motor included: Yes; Hardwired or plug-in: Plug-in
- Mounting hardware included: Yes
- Control unit/fan controller included: No (available as an optional add-on)
- Width: 3.96 in; Height: 16.5 in; Length: 21.2 in
- Kit includes: (1) Aluminum Fan Shroud, (1) 16-inch Slim Electric Fan, Mishimoto Lifetime Warranty
Frequently Asked Questions
What is included in the Mishimoto Performance Fan Shroud Kit?
The kit includes (1) Aluminum Fan Shroud, (1) 16-inch Slim Electric Fan, and the Mishimoto Lifetime Warranty.
How much airflow does the electric fan produce?
The included 16-inch high-flow electric fan produces over 1850 CFM of airflow, with a maximum CFM rating of 1850.
Will this shroud fit my stock radiator?
No, this fan shroud is designed to mount exclusively to the Mishimoto Performance Aluminum Radiator.
Does the kit come with a fan controller?
A control unit is not included by default, but this kit can optionally include the Mishimoto Adjustable Fan Controller Kit for complete control over coolant temperatures.
Which vehicles does this fan shroud kit fit?
It fits the 1967-1970 Ford Mustang Base, 1970 Ford Mustang Grande, 1970 Ford Mustang Mach 1, 1967 and 1969-1970 Ford Mustang Shelby GT-350, and the 1967-1969 Mercury Cougar Base.
Are there any installation notes I should know about?
The electric fan is shipped pre-installed on the shroud and may require additional wiring. Mishimoto notes that a standard length water pump may cause fitment issues when combined with the fan shroud and Mishimoto X-Line radiator, and recommends installing a short neck water pump and pulley to avoid clearance issues.
