Mishimoto 2011-2016 Ford 6.7L Powerstroke Air-to-Water Intercooler

Description

The Mishimoto MMINT-F2D-11SL is a direct-fit air-to-water intercooler built for the 2011-2016 Ford Super Duty 6.7L Powerstroke, replacing the factory stamped-and-stacked-plate cooler with a bar-and-plate core and cast aluminum end tanks that are precision TIG welded in place. Mishimoto developed this forced induction upgrade after learning that factory 6.7L Powerstroke air-to-water intercoolers were prone to internal leaks, and the result is a Micro-Wrinkle Silver finished cooler that also flowed 22-percent better than the stock unit on Mishimoto’s flow bench.

Because it moves more air through the 6.7L Powerstroke’s induction system, this performance induction intercooler gave Mishimoto’s stock test truck 40 lb-ft more torque on the dyno without any other modifications or a tune. The cast end tanks reduce the potential failure points found in cut-and-welded stock tanks, while the bar-and-plate core construction is built for efficient cooling and strength. As a forced induction system component engineered specifically for the 6.7L Powerstroke, it installs on a completely stock or modified truck and is backed by the Mishimoto Lifetime Warranty.

Vehicle Applications

This intercooler is a specific fit for the 2011-2016 Ford F-250, F-350, F-450, and F-550 Super Duty trucks equipped with the 6.7L Powerstroke. Coverage includes the F-250 XL, XLT, King Ranch, and Lariat from 2011-2016, the F-250 FX4 from 2011-2014, and the F-250 Base from 2015-2016. It also fits the F-350 XL, XLT, King Ranch, and Lariat from 2011-2016, as well as the F-450 Base, XL, XLT, King Ranch, and Lariat and the F-550 Base, XL, XLT, and Lariat over the same 2011-2016 span. Platinum trim coverage extends to the F-250, F-350, and F-450 Platinum from 2013-2016. This fitment is also reflected in CARB Executive Order D-759-4, which currently covers model years 2011-2016.

Features

• Direct fit for all 2011-2016 Ford 6.7L Powerstrokes
• 22-percent greater airflow than the stock 6.7L Powerstroke intercooler
• Dyno-proven 40 lb-ft torque gain without other modifications
• Cast end tanks are more durable than brazed or welded end tanks, eliminating potential leak points
• Bar-and-plate core for efficient cooling and unsurpassed strength
• No tune required — installs on a completely stock or modified truck
• Available in Micro-Wrinkle Silver, Micro-Wrinkle Black, or Micro-Wrinkle Blue powder-coated finish
• Covered by the Mishimoto Lifetime Warranty
• Patent No. US D907,063

Specifications

• Core Type: Bar-and-Plate
• Core Material: Aluminum
• Inlet Tank Material: Aluminum
• Core Height: 6.69 in
• Core Thickness: 4.48 in
• Core Length: 10.59 in
• Core Color: Silver
• Grade Type: Performance
• Inlet Fitting Gender: Male
• Outlet Fitting Gender: Male
• Universal or Specific Fit: Specific
• CARB EO Number: D-759-4 (covers model years 2011-2016)
• Includes: (1) Mishimoto Air-to-Water Intercooler, Mounting Hardware, Mishimoto Lifetime Warranty
